National secret algorithm support
Implement the HTTPS protocol based on the national secret SM2, SM3, SM4 algorithm suite and dual certificate system, and support self-adaptation based on client requests
International standard algorithm or national secret algorithm, support client-side and server-side mixed use of international standard algorithm and national secret algorithm, support many national secret browsing
device access.
Software Defined Application Delivery
Yunke application delivery system architecture adopts the original management and application delivery engine decoupling design, and all configuration management and monitoring functions provide
Provides Restful API (JSON) interface to realize CLI, WebGUI and third-party applications to seamlessly manage YK-ADC application delivery gateway. take the lead
100% software-defined application delivery!
Rich security features
Yunke application delivery system has built-in ACL access control, DDOS protection, HTTP_Flood protection, built-in WEB security protection,
Security protection functions such as HTTP protocol cleaning and SSL offloading ensure high application security.
Comprehensive protocol conversion functions
It supports the resolution and address translation of the IP address and port contained in the payload of the application protocol. The supported protocols include: DNS,
FTP, H.323, ICMP, SIP, etc.
Intelligent traffic handling:
L7 requests per second: 1.1M
L4 connections per second: 700k
Maximum L4 concurrent connections: 20M
Throughput: 30 Gbps L4
20Gbps L7
Hardware offload:
SSL/TLS:
ECC†: 6500 TPS (ECDSA P-256)
RSA: 6500 TPS (2k keys)
10Gbps bulk encryption
Software Architecture: 64-bit YK ADC OS
Processor: Intel 4 cores 8 threads
Memory: Standard 32GB memory, expandable up to 64GB memory
Hard Disk: 1T HDD replaceable SSD
Gigabit Ethernet ports: 6
Gigabit Fiber Ports (SFP): 4
10Gb fiber port (SFP+): support expansion
2 network expansion slots
Management interface: 1*serial port+1*shared gigabit electrical port 2 USB
Power supply: Support dual power supply
size:
455mm x44mm x 450mm
Deep 1U Industry Standard Rack Mount Chassis
Weight: 10kg (bare metal)
Operating temperature: 0℃~40℃ (working); -20℃~70℃ (storage)
Operating relative humidity: 10 to 85% RH, non-condensing
